6: Power Amplifier Board
6-12 PRC1099A-MS
R5 013560801 “RES, 5.6 OHM 1/4W 1% TK 1206”
R50 012470900 “RES, 47 OHM 1/10W 1% TK 0603”
R51 012470900 “RES, 47 OHM 1/10W 1% TK 0603”
R52 012100101 “RES, 1K OHM 0.1W 1% TK 0603”
R53 012100101 “RES, 1K OHM 0.1W 1% TK 0603”
R54 012100101 “RES, 1K OHM 0.1W 1% TK 0603”
R55 012100101 “RES, 1K OHM 0.1W 1% TK 0603”
R56 012100101 “RES, 1K OHM 0.1W 1% TK 0603”
R57 012100101 “RES, 1K OHM 0.1W 1% TK 0603”
R58 012330000 “RES, 330 OHM 1/10W 1% TK 0603”
R6 013560801 “RES, 5.6 OHM 1/4W 1% TK 1206”
R60 013270000 “RES,27 OHM 1/8W 5% TK 0805”
R61 013270000 “RES,27 OHM 1/8W 5% TK 0805”
R62 013360900 “RES, 36 OHM 1/8W 1% TK 0805”
R63 014220900 “RES, 22 OHM 1/4W 1% TK 1206”
R64 013470900 “RES, 47 OHM 1/8W 1% TK 0805”
R7 014137000 “RES, 137 OHM 1/4W 1% TK 1206”
R7A DNP “NULL PART, VACANT PCB LOCATION”
R8 013560801 “RES, 5.6 OHM 1/4W 1% TK 1206”
R9 013560801 “RES, 5.6 OHM 1/4W 1% TK 1206”
U1 033306039 “IC,GALI-84+ RF AMP 6 GHZ SOT89”
U3 033304106 “IC,OPA342 RRO OP-AMP SOT23-5”
U4 033304106 “IC,OPA342 RRO OP-AMP SOT23-5”
Table 6-3 Power Amplifier Board Parts List (009-00403 Rev. F)
Designator Part Number Description
