7: Antenna Tuner Board
PRC1099A-MS 7-13
Table 7-3 Antenna Tuner Driver Board Parts List (009-00502 Rev. K)
Designator Part Number Description
C1 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C10 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C11 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C12 241100 “CAP, 10UF TA 16V 20% DIP 0.1LS”
C13 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C14 241100 “CAP, 10UF TA 16V 20% DIP 0.1LS”
C15 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C16 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C17 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C18 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C19 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C2 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C20 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C21 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C22 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C23 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C24 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C25 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C26 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C27 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C28 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C29 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C3 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C30 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C31 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C32 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C5 210101 “CAP,100PF NP0 50V 5%.2LS DISK”
C7 241476 “CAP, 47UF TA 20V 20% 0.1LS”
D4 320102 “DIODE, 1N4001 1A 50V DO-41”
D5 320002 “DIODE, 1N4148/1N4150 DO-35”
L1 459032 “IND ASY,3T#30 MAGNET 1-490201”
