7: Antenna Tuner Board
7-16 PRC1099A-MS
Table 7-4 Antenna Tuner Board Parts List (009-00503 Rev. K)
Designator Part Number Description
C1 220470 “CAP, 47PF MICA 500V 5% DM15”
C2 220101 “CAP, 100PF MICA 500V 5% DM15”
C3 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C4 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C5 220220 “CAP, 22PF MICA 500V 5% DM15”
D1 320003 “DIODE,GE 1N34A”
D2 320002 “DIODE, 1N4148/1N4150 DO-35”
D3 320002 “DIODE, 1N4148/1N4150 DO-35”
K1 540066 “RELAY, SPDT 2A LATCH 12V”
K10 540066 “RELAY, SPDT 2A LATCH 12V”
K11 540066 “RELAY, SPDT 2A LATCH 12V”
K12 540066 “RELAY, SPDT 2A LATCH 12V”
K13 540066 “RELAY, SPDT 2A LATCH 12V”
K14 540066 “RELAY, SPDT 2A LATCH 12V”
K15 540080 “RELAY,DPDT 2 AMP SEALED”
K16 540056 “RELAY, SPDT 12VDC”
K17 540066 “RELAY, SPDT 2A LATCH 12V”
K2 540066 “RELAY, SPDT 2A LATCH 12V”
K3 540066 “RELAY, SPDT 2A LATCH 12V”
K4 540066 “RELAY, SPDT 2A LATCH 12V”
K5 540066 “RELAY, SPDT 2A LATCH 12V”
K6 540066 “RELAY, SPDT 2A LATCH 12V”
K7 540066 “RELAY, SPDT 2A LATCH 12V”
K8 540066 “RELAY, SPDT 2A LATCH 12V”
K9 540066 “RELAY, SPDT 2A LATCH 12V”
L1 459005 “IND, 0.164 UH 7T#22 1-490030”
L10 459118 “IND, 47.5 UH 74T #30 2-490001”
L2 459004 “IND, 0.406 UH 11T#22 1-490030”
L3 459003 “IND, 0.970 UH 15T#22 1-490010”
L4 459002 “IND, 2.06 UH 23T#22 1-490010”
L5 459006 “IND, 4.45 UH 23T#22 2-490010”
