8: Synthesizer Board
PRC1099A-MS 8-19
Table 8-3 Synthesizer Board Parts List (009-00606 Rev. P)
Designator Part Number Description
C1 021475000 “CAP, 4.7UF 25V X7R 10% 1206”
C10 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C100 021475000 “CAP, 4.7UF 25V X7R 10% 1206”
C101 021829000 “CAP, 8.2PF, NP0, 100V, 0.25PF, 0805”
C102 021121000 CAP 120PF NP0 100V 5% 0805
C103 021121000 CAP 120PF NP0 100V 5% 0805
C104 021331000 “CAP, 330PF NP0 100V 5% 0805”
C105 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C106 021100000 “CAP, 10PF, NP0, 100V, 5%, 0805”
C107 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C108 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C109 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C11 021475000 “CAP, 4.7UF 25V X7R 10% 1206”
C110 021331000 “CAP, 330PF NP0 100V 5% 0805”
C111 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C112 DNP “NULL PART, VACANT PCB LOCATION”
C113 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C114 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C115 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C116 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C117 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C118 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C119 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C12 021475000 “CAP, 4.7UF 25V X7R 10% 1206”
C120 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C121 021102000 “CAP, 1000PF NP0 100V 5% 0805”
C122 021103000 “CAP, 0.01UF X7R 50V 5% 0805”
C123 025183000 “CAP, 0.018UF PPS 16V 2% 1206”
C124 025474000 “CAP, 0.47UF PET 16V 20% 1206”
C125 021102007 “CAP, 1000PF NP0 200V 5% 1206”
C126 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
