8: Synthesizer Board
8-30 PRC1099A-MS
U14 033305032 “IC,74TVC3306 VOLT CLAMP SSOP-8”
U15 033304042 “IC, LT1763 VREG ADJ SOIC-8”
U16 065117001 “VCO, RFVC-6600 10V 75-110 MHZ”
U17 033304079 “IC,LT6230-10 RF OP AMP SOT23-6”
U18 033303117 “IC,ADF4002 PLL SYN TSSOP-16”
U2 034402009 “IC, LT1767 SWT VREG ADJ MSOP8”
U3 033304042 “IC, LT1763 VREG ADJ SOIC-8”
U4 033304042 “IC, LT1763 VREG ADJ SOIC-8”
U5 033304042 “IC, LT1763 VREG ADJ SOIC-8”
U6 033304079 “IC,LT6230-10 RF OP AMP SOT23-6”
U7 033306014 “IC, RF AMP MAR-7SM SMT”
U8 033306014 “IC, RF AMP MAR-7SM SMT”
U9 033303103 “IC, AD9959 DDS LFCSP-56”
VR1 010103000 POT 10K ST-5 14T 0.25W 6MM SMT
Y1 065107001 “TCXO, C2310 100MHZ 3.3V SMT”
Table 8-3 Synthesizer Board Parts List (009-00606 Rev. P)
Designator Part Number Description
