9: Processor Board
PRC1099A-MS 9-17
Table 9-7 Processor Board Parts List (009-10702 Rev. W)
Designator Part Number Description
BT1 750057 “BATT, CR2450, 0.54AH, 3V, LI, 3-TAB COIN”
C1 020101 “CAP,100PF 100V 5% NP0 1206”
C10 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C11 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C13 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C14 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C15 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C16 021102 “CAP, 1000PF, X7R, 50V, 10%, 1206”
C17 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C18 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C19 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C2 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C20 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C21 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C22 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C23 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C24 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C25 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C26 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C27 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C28 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C29 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C3 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C30 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C31 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C32 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C33 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C34 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C35 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C36 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C37 022225000 “CAP, 2.2UF TA 20V 10% 3528-21”
