9: Processor Board
9-22 PRC1099A-MS
U16 033077 “IC, 74HCT32 QUAD 2-I OR SOIC14”
U17 033076 “IC, 74HCT04 HEX INVERTER SO14”
U18 033030 “IC,93C46 SER EEPROM 1K SOIC-8”
U19 033024 “IC, MC33079D, SM, SO-14”
U21 033084 “XSTR,SI9405DY PWR P-FET SO-8”
U4 033078 “IC,SRAM MS6264 8KX8 SOP-28”
U5 033078 “IC,SRAM MS6264 8KX8 SOP-28”
U6 033032 “IC, ADC0804 8-BIT A/DC SOW-20”
U7 033046 “IC,74HC4051 ANLG MUX/DEM SOW16”
U8 033305005 “IC, MAX242EWN RS232 XCVR SO-18”
U9 033019 “IC, MAX695, SM, SOW-16”
XJU1 621105 “MICRO SHUNT, 0.10 IN 1.5A SN”
XJU2 621105 “MICRO SHUNT, 0.10 IN 1.5A SN”
XJU3 621105 “MICRO SHUNT, 0.10 IN 1.5A SN”
XJU4B 621105 “MICRO SHUNT, 0.10 IN 1.5A SN”
XU2 621021 “SOCKET, IC DIP-32 SCREW”
XU20 621009 “SOCKET,28 PIN DIP”
XU3 621021 “SOCKET, IC DIP-32 SCREW”
Y1 361108 “XTAL,4.9152 MHZ HC49/US CASE”
Y2 361081 “CRYSTAL,3.579545 MHZ”
Table 9-7 Processor Board Parts List (009-10702 Rev. W)
Designator Part Number Description
To Next Page
