10: Display Board
PRC1099A-MS 10-11
Table 10-5 Display Board Parts List (009-10801 Rev. L)
Designator Part Number Description
C1 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
C2 237101 “CAP, 100UF AL 16V 20% 6.3X7X2.5LS”
C3 237101 “CAP, 100UF AL 16V 20% 6.3X7X2.5LS”
C4 241020 “CAP, 2.2UF, TA, 16V, 20%, DIP, 0.1LS”
J2 610208 “HEADER,1X10 MLX RA+SB LOCK 0.1”
J3 610208 “HEADER,1X10 MLX RA+SB LOCK 0.1”
J4 610208 “HEADER,1X10 MLX RA+SB LOCK 0.1”
LK1 620073 “HEADER, 2X3 MLX 0.1 STR”
LK2 620073 “HEADER, 2X3 MLX 0.1 STR”
LK3 620073 “HEADER, 2X3 MLX 0.1 STR”
Q1 310064 “XSTR,2N6427 NPN DARL TO-92”
Q2 310003 “XSTR, 2N3567 NPN 300MA TO92”
R1 113184 “RES, 180K OHM 1/8W 5% CF”
R2 113104 “RES,100K OHM 1/8W CF 5%”
R3 113104 “RES,100K OHM 1/8W CF 5%”
R4 113100 “RES,10 OHM 1/8W 5% FILM”
T1 410019 “XFMR, AUDIO MINI 600CT - 600CT”
U1 033083 “IC,PCF8576T DISPLAY DR SOT190”
U2 320806 “LCD,CUSTOM PRC1099”
U3 330209 “IC, 4020B 14-B BIN CNTR DIP16”
XU2 610223 “SOCKET STRIP,SIL,27 CONT,.100”
XU3 621004 “SOCKET, IC DIP-16 PIN”
