4: 1650 kHz IF Board
PRC1099A-MS 4-9
Table 4-3 1650 kHz IF Board Parts List (009-00202 Rev. R)
Designator Part Number Description
C1 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C10 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C11 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C12 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C13 241040 “CAP,T,4.7UF,16V,20%,RA,.1SP”
C14 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C15 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C16 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C17 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C18 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C19 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C20 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C21 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C22 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C23 237100 “CAP, 10UF AL 16V 20% 4X5X1.5LS”
C25 021104 “CAP, 0.1UF, X7R, 50V, 10%, 1206”
C3 2751001 “CAP, 10PF NPO 50V 5% RAD 0.1S”
C5 221101 “CAP, 100PF MICA 300V 5% DM5”
C6 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C7 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C8 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C9 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
D1 320002 “DIODE, 1N4148/1N4150 DO-35”
D2 320002 “DIODE, 1N4148/1N4150 DO-35”
D3 320002 “DIODE, 1N4148/1N4150 DO-35”
D4 320002 “DIODE, 1N4148/1N4150 DO-35”
D5 320002 “DIODE, 1N4148/1N4150 DO-35”
D6 320002 “DIODE, 1N4148/1N4150 DO-35”
D7 320002 “DIODE, 1N4148/1N4150 DO-35”
J1 610235 “HEADER, 1X4 MLX RA+SB LOCK 0.1”
J2 610510 “CONN, SMB PCB JACK-F RT AGL TH”
