4: 1650 kHz IF Board
PRC1099A-MS 4-11
R6 113104 “RES,100K OHM 1/8W CF 5%”
R7 113333 “RES,33K OHM 1/8W CF 5%”
R8 113392 “RES,3.9K 1/8W 5% CARBON FILM”
R9 013680 “RES,68 OHMS 1/4W 5% SMT”
T1 420018 INDUCTOR IF 1650KHZ
T2 420018 INDUCTOR IF 1650KHZ
T3 420018 INDUCTOR IF 1650KHZ
T4 420018 INDUCTOR IF 1650KHZ
Y1 361001 “CRYSTAL, FILTER, TW100”
Y2 361004 “CRYSTAL, FILTER, TW100”
Y3 361003 “CRYSTAL, FILTER, TW100”
Y4 361002 “CRYSTAL, FILTER, TW100”
Y5 361001 “CRYSTAL, FILTER, TW100”
Y6 361004 “CRYSTAL, FILTER, TW100”
Table 4-3 1650 kHz IF Board Parts List (009-00202 Rev. R)
Designator Part Number Description
To Next Page
