5: Mixer Board
PRC1099A-MS 5-19
C73 DNP “NULL PART, VACANT PCB LOCATION”
C74 237220 “CAP,22MF 16V ELECT VRT”
C75 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C76 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C77 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C79 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C8 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C80 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C81 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C82 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C83 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C84 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C85 275104 “CAP, 0.1UF X7R 50V 10% RAD 0.1S”
C86 214103 “CAP, 0.01UF X7R 50V 10% 0.1LS”
C87 021104000 “CAP, 0.1UF X7R 25V 5% 0805”
C9 221101 “CAP, 100PF MICA 300V 5% DM5”
D1 320005 “DIODE, BA482 PIN SWITCH DO-34”
D11 320005 “DIODE, BA482 PIN SWITCH DO-34”
D12 320002 “DIODE, 1N4148/1N4150 DO-35”
D13 320005 “DIODE, BA482 PIN SWITCH DO-34”
D14 DNP “NULL PART, VACANT PCB LOCATION”
D15 DNP “NULL PART, VACANT PCB LOCATION”
D16 320002 “DIODE, 1N4148/1N4150 DO-35”
D17 320005 “DIODE, BA482 PIN SWITCH DO-34”
D18 037700008 “DIODE, GBLC03C, TVS, BI, 3VBRK, SOD323”
D2 320005 “DIODE, BA482 PIN SWITCH DO-34”
D3 320002 “DIODE, 1N4148/1N4150 DO-35”
D7 320005 “DIODE, BA482 PIN SWITCH DO-34”
K1 540060 “RELAY, SPDT, 9VDC”
L1 045000001 “BEAD, FERRITE, Z=120, 0.4A, 25%, 1206”
L11 045000001 “BEAD, FERRITE, Z=120, 0.4A, 25%, 1206”
L12 430021 “IND, 22UH, FE, 140MA, 10%, IM-2”
Table 5-4 Mixer Board Parts List (009-00301 Rev. AU)
Designator Part Number Description
