Theheartratewindowdisplaystheheartrateoftheuser(1to4).Whenonly
theupwardpointingarrowisdisplayedinthemiddle,thenthismeansthatthe
heartrateistoolowtoensureaneffectivetraining.Inversely,whenonlythe
downwardpointingarrowisdisplayedthentheheartrateistoohigh.Ifthe
arrowstartsblinkingthentheloadistoohighandtheusershouldmoderatethe
training.Thearrowspointingtotheleftindicatetheusercurrentlyselected.
Dissipatedenergy(inkJoule)andelapsedtimedisplay:thiswindowshowsthe
timeelapsedsincestartingtrainingorhowmanykJoulehavebeendissipated.
UsetheInfokeytoswitchbetweenthetwovalues.Whenthedeviceisunused
foranextendedperiodoftimethiswindowdisplaysthelocaltime.
TheRPMwindowindicatesthespeedinrevolutionperminute.Ifthedownward
pointingarrowontherightsideisdisplayedthentheusershouldpedalfaster,
theusershouldpedalsloweriftheleftarrowisdisplayed.
(+=pedalfaster,-=pedalslower)
Speedanddistancewindow:thiswindowshowstheactualspeedanddistance
covered.UsetheInfokeytoswitchbetweenthesetwovalues.
Thewattwindowshowstheloadinwatt.Italsoshowstherelaxvaluewith
therelaxationfunction.
Thegraphicscreendisplaystheprograms.Theload(inwatt)isshownonthe
scaleontheleftsideofthescreen.Thetrainingtimeisshownontheloweraxis.
Inheartratecontrolledprogramsthesystemdisplays100beatsperminuteat
the200wattpositionsincetheheartrateisdisplayedtoascalecorresponding
toonehalfofthewattscale.
Note:theillustrationsmaybechangedwithoutnotice!
