Davis Instruments Vantage Pro2 User Manual

Selecting Units of Measure
19
these steps cycles through the units available for barometric pressure: millibars, mil-
limeters, inches, and hectoPascals.
Wind Speed and Direction
Press WIND to select wind speed.
3. Wind speed may be displayed in miles per hour (m.p.h.), kilometers per
hour (km/h), meters per second (m/s), and knots (knots). The 10 minute
average wind speed will be displayed in the ticker.
A solid arrow within the compass rose indicates the current wind direction. Arrow
caps indicate up to six different 10-minute dominant wind directions to provide a
history of the dominant wind directions for the past hour.
4. Press WIND a second time to display the wind direction
in degrees instead of the wind speed. When displayed in
degrees, Due North displays as 360
º
for consoles with
firmware dated May 2005 or later. Previous releases
marked Due North at 0
º
.
Each additional WIND key press toggles the display
between wind speed and wind direction in degrees.
Note: If your anemometer arm is not pointing true north, you should recalibrate the wind
direction reading on your console. See “Calibrate Wind Direction Reading” on
page 25 for more information.
Outside and Inside Temperature
1. Press TEMP to select outside temperature.
BAROMETER
mb
BAROMETER
BAROMETER
mm
in
Displaying Units: Barometric Pressure Units: millibars (mb), millimeters (mm) and
N
W
NE
SESW
Vertical Scale: X10
WIND
RAIN YEAR
in
TEMP OUT
HUM IN
HUM OUT
DAILY RAIN
in
TEMP IN
hPa
BAROMETER
STATION NO.1
F
F
F
MPH
Last 24 hrs
hr
Every 1
S
E
NW
pm
TEMP IN
F
TEMP OUT
F
HEAT INDEX
N
W
NE
SESW
WIND
MPH
E
S
NW
Wind Direction, Outside and Inside Temperature
WIND
360˚ N
˚
45˚ NE
˚
90˚ E
˚
135˚ SE
˚
180˚ S
˚
225˚ SW
˚
270˚ W
˚
315˚ NW
˚

Davis Instruments Vantage Pro2 Specifications

General

Update Interval	2.5 seconds
Wind Direction Resolution	1°
Wind Direction Range	0 to 360°
Rain Collector	Self-emptying tipping bucket
UV Index Range	0 to 16
Solar Radiation Range	0 to 1800 W/m²
Console Display	LCD with backlight
Wireless Transmission Range	1000 feet (300 meters) line of sight
Temperature Range	-40 to 150 °F (-40 to 65 °C)
Humidity Range	1 to 100%
Barometric Pressure Range	16.00 to 32.50 inHg (540 to 1100 hPa)
Wind Speed Range	0 to 200 mph (0 to 322 km/h)
Rain Collector Size	0.01 inch (0.2 mm) resolution
Rain Measurement Accuracy	±4% at rates up to 2 in/hr (50 mm/hr)
Power Supply	Solar-powered with battery backup
Console Power Supply	AC adapter or 3 C batteries
