DAVIS CT Series - MSD STYLE IGNITION (DISCRETE)

28
CT Series Traction Control
www.moretraction.com
MSD® style Ignition (discrete)
(Set Points Output to “None”)
Connect pin 1 to 6-20v+ (Battery Positive).
Connect pin 4 to 6-20v- (Battery Ground).
Connect pin 7 to positive distributor pickup wire.
This should be the purple wire coming out of the
ignition box.
A toggle switch may be used, if desired to turn the
unit on/off.
*Max Retard=20 deg
IMPORTANT: THE POINTS OUTPUT
MUST BE SET TO “None” IN THE
ADVANCED MENU FOR ALL
DISCRETE MODES.
