CT Series Traction Control
www.moretraction.com
Appendix B
Weather Pack Plug Option
CT-1, CT2-SL and CT3-SL series units are supplied
with a Weather Pack Plug or Weather Pack adapter
for ease of installation.
These units also have the Molex Nano-Fit plug
located in the rear cover for use with optional add-
ons or future features.
3 Pin Weather Pack Plug
Connect the terminal marked “A” (RED wire) to
Battery Positive. (Nano-Fit Pin 1)
Connect the terminal marked “B” (Black wire) to
Battery Negative. (Nano-Fit Pin 4)
Connect the terminal marked “C” (Purple or White
wire) to Positive distributor pickup wire. (Nano-Fit Pin 7)
