27
220i
DriveRack
®
User Manual
PEQ On/Off
Turns the PEQ band on and off.
The following figure shows the constant Q parametric filter.
Flatten/Restore
This parameter either flattens the PEQ or restores the PEQ to its original shape.
Type
This parameter selects the PEQ type. Types include: 1. Bell-All parametrics are bell-shaped 2. HShelf -
One shelf is High, while all others are bell 3. LShelf - One shelf is Low, while all others are bell and 4.
LHShelf - One shelf is High and one is Low, and the others are bell.
Band (1-4) Frequency 20Hz to 20kHz
Selects the frequency of the selected band of the parametric EQ.
Level (1-4) -12dB to 12dB
Sets the peak level of the selected parametric EQ.
Q (1-4) 0.20 to 16 dB
Sets the Q or Bandwidth of the selected Parametric EQ.
Detailed Parameters
Section 3
