Crossover Types
Ref # # Of Inputs/Outputs Crossover Name Crossover Configuration Icon Supported Speaker Configuration
7 2x3 Mono Mains x2 + Aux Sub
8 1x4 Mono Mains x2 + Mono Subs x2
9 2x4 Mono Mains x2 + Aux Subs x2
10 1x3 Mono Mains x3
11 1x4 Mono Mains x3 + Mono Sub
12 2x4 Mono Mains x3 + Aux Sub
13 1x5 Mono Mains x3 + Mono Subs x2
LEGEND: M=Mono, L=Left,
C=Center, R=Right, A=Aux
LEGEND: FR=Full Range, S=Sub,
AS=Aux Sub, H=High, M=Main or
Mid, L=Low
