35
Crossover Types
Ref # # Of Inputs/Outputs Crossover Name Crossover Configuration Icon Supported Speaker Configuration
14 2x5 Mono Mains x3 + Aux Subs x2
15 1x6 Mono Mains x3 + Mono Subs x3
16 2x6 Mono Mains x3 + Aux Subs x3
17 1x2 Mono 2Way
18 1x3 Mono 2Way + Mono Sub
19 2x3 Mono 2Way + Aux Sub
20 1x4 Mono 2Way x2
LEGEND: M=Mono, L=Left,
C=Center, R=Right, A=Aux
LEGEND: FR=Full Range, S=Sub,
AS=Aux Sub, H=High, M=Main or
Mid, L=Low
