36
Crossover Types
Ref # # Of Inputs/Outputs Crossover Name Crossover Configuration Icon Supported Speaker Configuration
21 1x5 Mono 2Way x2 + Mono Sub
22 2x5 Mono 2Way x2 + Aux Sub
23 1x6 Mono 2Way x2 + Mono Subs x2
24 2x6 Mono 2Way x2 + Aux Subs x2
25 1x6 Mono 2Way x3
26 1x3 Mono 3Way
27 1x4 Mono 3Way + Mono Sub
LEGEND: M=Mono, L=Left,
C=Center, R=Right, A=Aux
LEGEND: FR=Full Range, S=Sub,
AS=Aux Sub, H=High, M=Main or
Mid, L=Low
