37
Crossover Types
Ref # # Of Inputs/Outputs Crossover Name Crossover Configuration Icon Supported Speaker Configuration
28 2x4 Mono 3Way + Aux Sub
29 1x6 Mono 3Way x2
30 1x4 Mono 4Way
31 1x5 Mono 5Way
32 1x6 Mono 6Way
33 2x2 Stereo Full Range
34 2x3 Stereo Mains + Mono Sub
LEGEND: M=Mono, L=Left,
C=Center, R=Right, A=Aux
LEGEND: FR=Full Range, S=Sub,
AS=Aux Sub, H=High, M=Main or
Mid, L=Low
