EtherSeries EMB-02 User’s Guide
6
LED Indicators
There are two red LED indicators on the panel below the LAN
connector and two green LED indicators adjacent to the serial
ports.
LED Indicators
• The LAN LED is the Ethernet Status indicator. It is lit when
there is a valid 10/100BaseT Ethernet connection.
• This LED flickers off and on with activity on the Ethernet
(even if the activity isn't directly to this unit).
• The green LEDs flicker off and on with EMB-02 transmit
activity on the two serial port.
• The red RUN LED flickers off and on with ethernet transmit
activity from the EMB-02.
