EtherSeries EMB-02 User’s Guide
28
Main Menu Option 7.
Display Configuration Settings
Selecting (7) from the Main Menu will display the following
information:
Modbus Server Gateway: V1.2
LOCAL UNIT CONFIGURATION:
Local Address: 205.166.54.141 Serial NO: 00:60:E9:00:53:70
Gateway Address: (NOT SET) Subnet Mask: 255.255.255.0
Name of Contact Person: Supervisor
Device Name: GW005370
Physical Location: Head Office
IP Fragmentation: ALLOWED
MANAGER CONFIGURATION:
Entry Manager_IP_Addr
***** ***************
1. 0.0.0.0
2. 0.0.0.0
3. 0.0.0.0
4. 0.0.0.0
[Press any key to continue]
PORT 1 CONFIGURATION:
Baud Rate: 38400 RTS/CTS Handshake: No
Parity: EVEN -Delay after RTS Active: 0 ms
Data: 8 Bits -Wait CTS Active: 0 ms
Stop: 1 Bit -Delay after CTS Active: 0 ms
RS485: 4-wire -Delay dropping RTS: 0 ms
