Configuration
29
PORT 2 CONFIGURATION:
Baud Rate: 19200 RTS/CTS Handshake: No
Parity: NONE -Delay after RTS Active: 0 ms
Data: 8 Bits -Wait CTS Active: 0 ms
Stop: 1 Bit -Delay after CTS Active: 0 ms
RS485: 4-wire -Delay dropping RTS: 0 ms
[Press any key to continue]
MODBUS/TCP CONFIGURATION:
TCP Port: 502
Connection Timeout: 120 seconds
Return Modbus/TCP Exceptions: No
Discard Multiple Polls: Yes
Slave Address 0: Broadcast
Fixed Slave Address: 0
MODBUS SERIAL CONFIGURATION:
Port 1 Modbus Protocol: RTU Port 2 Modbus Protocol: RTU
Port 1 Slave Address Low: 1 Port 2 Slave Address Low: 1
Port 1 Slave Address High: 247 Port 2 Slave Address High: 247
Port 1 Response Timeout: 2000 Port 2 Response Timeout: 250
Port 1 Character Timeout: 50 Port 2 Character Timeout: 50
[Press any key to continue]
CURRENT STATISITCS:
Network packets received: 595
Network packets transmitted: 144
Network packet errors: 0
Port bytes received: 0
Port bytes transmitted: 0
[Press any key to continue]
This option displays the configuration and some counters.
