EtherSeries EMB-02 User’s Guide
16
Entering Data
Enter the number of the field you wish to change, followed (on
the same line) by a space and the data for that field.
Example
On screen one, to set the IP address (field 1) to 192.168.1.10
=>1 192.168.1.10
Menu Options
Main Menu Option 1.
Setting IP Addresses
Selecting 1 (1 Local IP Address) from the Main Menu will
result in a screen which is similar to the following.
Choose a Number =>
LOCAL UNIT CONFIGURATION:
Local Address: 205.166.54.141 Serial NO:
00:60:E9:00:53:70
Gateway Address: (NOT SET) Subnet
Mask: 255.255.255.0
Name of Contact Person: Supervisor
Device Name: GW005370
Physical Location: Head Office
IP Fragmentation: ALLOWED
SET LOCAL UNIT CONFIGURATION:
1 Local IP Address
2 Gateway IP Address
3 Subnet Mask
4 Name of Contact Person
