Configuration
19
Enter Command =>
This screen shows a table containing four (4) entries. By
default, all entries are blank. These entries provide a security
feature. Only a user at one of the IP addresses shown can
manage the unit. (All users on the LAN can still use the
gateway, but not configure it.)
If the entries are blank, then any user on the LAN can
configure the gateway.
Entries in the table cannot be edited, but commands are
provided to insert (SET) and delete (CLEAR) entries.
Main Menu Options 3 & 4.
Serial Port Configuration
Selecting (3) from the Main Menu will result in the following
screen for port 1. Selecting (4) from the Main Menu will result
in a similar screen for port 2.
PORT 1 CONFIGURATION:
Baud Rate: 38400 RTS/CTS Handshake:
No
Parity: EVEN -Delay after RTS Active:
0 ms
Data: 8 Bits -Wait CTS Active:
0 ms
Stop: 1 Bit -Delay after CTS Active:
0 ms
RS485: 4-wire -Delay dropping RTS:
0 ms
SET PORT CONFIGURATION:
1 Baud Rate [0=230400, 1=115200,
2=57600, 3=38400, 4=19200,
