EtherSeries EMB-02 User’s Guide
20
5=9600, 6=4800,
7=2400, 8=1200, 9=600, 10=300]
2 Parity bit [0=None, 1=Odd,
2=Even]
3 Data bits [0=7bits, 1=8bits]
4 Stop bits [0=1bit, 1=2bits]
5 RS485 Mode [0=4-wire, 1=2-wire]
6 RTS/CTS Handshake [0=no, 1=yes]
7 Delay after RTS Active [0 - 5000 ms]
8 Wait CTS Active [0 - 5000 ms]
9 Delay after CTS Active [0 - 5000 ms]
10 Delay dropping RTS [0 - 5000 ms]
0 -- Return to previous menu.
EXAMPLE: To set the baud rate to 19200
=> 1 4
Enter Command =>
This screen configures the settings for the serial ports. The
settings used should match the device connected to the serial
ports of the gateway.
Baud Rate
Speeds between 300 bps and 230.4Kbps are supported.
Parity
Configure parity bits for either NONE, ODD, or EVEN to match
your serial devices.
Data Bits
Configure the word length to seven or eight bits. This does
NOT include the parity bit.
Stop Bits
Configure the number of stop bits to either one or two.
