DCB Ether Series - Main Menu Option 5. MODBUS TCP Configuration

Configuration
23
Main Menu Option 5.
MODBUS TCP Configuration
Selecting (5) from the Main Menu will result in the following
screen:
MODBUS/TCP CONFIGURATION:
TCP Port: 502
Connection Timeout: 120 seconds
Return Modbus/TCP Exceptions: No
Discard Multiple Polls: Yes
Slave Address 0: Broadcast
Fixed Slave Address: 0
SET MODBUS/TCP CONFIGURATION:
1 TCP Port
2 Connection Timeout [10 - 3600
seconds]
3 Return Modbus/TCP Exceptions [0=no, 1=yes]
4 Discard Multiple Polls [0=no, 1=yes]
5 Slave Address 0 [0=Map to Addr
1, 1=Broadcast]
6 Fixed Slave Address [0=Not Fixed,
1-247 = Fixed address]
0 -- Return to previous menu
EXAMPLE: To set the Connection Timeout to 75
seconds
=> 2 75
Enter Command =>
Use this screen to configure Modbus/TCP configuration
values.
