EtherSeries EMB-02 User’s Guide
26
8 Port 2 Slave Address High [1 - 247]
9 Port 2 Response Timeout [5 - 5000 ms]
10 Port 2 Character Timeout [5 - 5000 ms]
0 -- Return to previous menu
EXAMPLE: To set the Port 1 Modbus Protocol to
RTU
=> 1 0
Enter Command =
Use this screen to configure Modbus serial configuration
values. For each of the ports (1 or 2) configure the following…
Modbus Protocol
Select the appropriate Modbus protocol to match the RTU(s) on
this port. Select either 0 for RTU or 1 for ASCII
Slave Address Low
Configures the lowest address of an RTU on this port.
Slave Address High
Configures the highest address range of an RTU on this port. If
the ranges of port one and port two overlap, addresses in the
overlap will be sent to port one.
Response Timeout
This parameter specifies the maximum amount of time to wait for
the first character of a response from a slave device
Character Timeout
This parameter specifies the maximum amount of time to wait for
reception of successive characters. For Modbus/RTU mode,
this timer is used to determine the end-of-message. The
