OVERVIEW
INSTRUCTIONS PURPOSE
These instructions were prepared by the manufacturer and are an integral part of the product. The operations described are inten-
ded for adequately trained and qualified operators and must be carefully read and preserved for future reference.
Chapters “2 WARNINGS SUMMARY” and “4 OPERATING INSTRUCTIONS” contain all the information that DEA System provides
so that the product may constantly satisfy the Essential Safety Requirements prescribed by the Machinery Directive (European Directive
2006/42/CE).
Read these chapters carefully because they contain important instructions for safe installation, use and maintenance and important
warnings regarding the residual risks remaining even after all the safety devices and measures described have been applied.
The product is designed to be integrated into complete closing systems which specific legislative references are applied for. The
chapter “7 START-UP” provides some directions for compliance with the Essential Safety Requirements for particular types of closures.
1 PRODUCT CONFORMITY
MAC gate operator bears the CE label. DEA System guarantees the conformity of the product to European Directives 2006/42/
CE regarding “machinery safety”, 2004/108/CE “electromagnetic compatibility” and 2006/95/CE “low voltage electrical equipment”.
See Declaration of Conformity.
2 WARNINGS SUMMARY
Read these warnings carefully; failure to respect the following warnings may cause risk situations.
WARNING Using this product under unusual conditions not foreseen by the manufacturer can create situations of danger, and
for this reason all the conditions prescribed in these instructions must be respected.
WARNING DEA System reminds all users that the selection, positioning and installation of all materials and devices which make
up the complete automation system, must comply with the European Directives 2006/42/CE (Machinery Directive), 2004/108/CE
(electromagnetic compatibility), 2006/95/CE (low voltage electrical equipment). In order to ensure a suitable level of safety, besides
complying with local regulations, it is advisable to comply also with the above mentioned Directives in all extra European countries.
WARNING Under no circumstances must the product be used in explosive atmospheres or surroundings that may prove corrosive
and damage parts of the product.
WARNING All installation, maintenance, cleaning or repair operations on any part of the system must be performed exclusively
by qualified personnel with the power supply disconnected working in strict compliance with the electrical standards and regulations
in force in the nation of installation.
WARNING Using spare parts not indicated by DEA System and/or incorrect re-assembly can create risk to people, animals and
property and also damage the product. For this reason, always use only the parts indicated by DEA System and scrupulously follow
all assembly instructions.
