TYPE
00
TYPE
01
TYPE
02
TYPE
03
TYPE
04
INPUTS CONFIGURATION
PARAMETERS
Allocation of CHANNEL 1 of remotes
• 000: NONE (unused)
• 001: START (start)
• 002: PEDESTRIAN (pedestrian)
• 003: OPEN (separated open)
• 004: CLOSED (separated close)
• 005: Unused
• 006: Unused
• 007: ELOCK-IN (electric-lock activation. See P062)
• 008: AUX_IN (with NET_EXP only)
CH1
Allocation of CHANNEL 2 of remotes
Allocation of CHANNEL 3 of remotes
Allocation of CHANNEL 4 of remotes
Selection of type of remotes
• 000: HCS x-code
• 001: HCS rolling-code
• 002: Dip-switch
OPERATORS CONFIGURATION
PARAMETERS
Selection type of operators
Warning: Selecting the OLI operators, all indicated values related to the operator force (P037 - P038 - P039 -
P040), are automatically set to 100% without any possibility of change. For this type of operator, the obstacle
detection is not active and the adjustment of the thrust force can be executed acting on the operator valves
only.
• 000: LATO
• 001: LOOK - MAC - STING
• 002: GHOST 100/200
• 003: 500 - 500MT - 502 - 502EN -
902EN - PASS - 550PL
• 004: STOP - 500P - 500MT/RF - 502R -
502R/EN - 502L - 902R - 902R/EN/F
• 005: 6NET - OLI
• 006: 9NET
• 007: GULLIVER - REV
Selected work with or without encoders.
WARNING: P029 must be set correctly before performing the procedure for programming
• 000: motors with encoder
• 001: engines without encoder. Slow down is activated
• 002: engines without encoder. Slow down not activated
Selectioning operators number
• 001: one operator
• 002: two operators
OPERATING PARAMETERS
Operators speed adjustment during slow-down while opening
Warning: For operators without
encoder, speedness during the
stroke while opening/closing
(100%) and slow down speedness
while opening/closing (30%)
are xed independently from set
values.
15%tot........................100%tot
Operators speed adjustment during the stroke while opening
15%tot........................100%tot
Operators speed adjustment during the stroke while closing
15%tot........................100%tot
Operators speed adjustment during slow-down while closing
15%tot........................100%tot
Slow down duration adjustment while opening
0%tot............................80%tot
Slow down duration adjustment while closing
0%tot............................80%tot
Operator 1 force adjustment while opening
(if = 100% obstacle detection deactivated)
Warning: For operators without
encoder: while adjusting the force,
obstacle detection during the
slowdown is ignored.
15%tot…...........................100%tot
Operator n.1 force adjustment while closing
(if = 100% obstacle detection deactivated)
15%tot…...........................100%tot
TYPE 00 - 01 - 03 ONLY: Operator n.2 force adjustment while opening
(if = 100% obstacle detection deactivated)
15%tot…...........................100%tot
TYPE 02 - 04 ONLY: Secondary force adjustment in closing: adjusts
the motor’s force during the last part of the closing movement dened
by P058
0%tot...................................100%tot
Operator n.2 force adjustment while closing
(if = 100% obstacle detection deactivated)
0%tot...................................100%tot
Automatic closing times adjustment
(if = 0 automatic closing deactivated)
0sec...................................255sec
