4 CONFIGURATION OF THE CONTROL PANEL
The universal control unit NET230N can be used for the management of the following types ( ) of closures motorized by DEA Sy-
stem: swing and sliding gates, overhead doors and barriers.
In order to ensure maximum adaptability to each
of closure, the control board provides an initial procedure, performed only at the
rst turn, for the optimal conguration of inputs, outputs and parameters (see diagram ). Once congured, the control panel will operate
in the mode “dedicated” to the of selected closing. After performing the initial conguration it is sufcient to execute the standard
programming for the installation on which it is operating.
All settings remain in memory even in the case of subsequent are-ups (see diagram ).
If necessary the of congured closing can be later adjusted following diagram .
FIRST CONTROL BOARD IGNITION
Conguration after the rst ignition
For the rst control panel ignition, proceed as fol-
lows:
1. Apply power, the display shows in sequence the
writing “
” and “ ” ashing;
2. Press the button and hold for 5 seconds until
the display shows on the display;
3. Acting on the and keys, select the desired
conguration depending on the type of installa-
tion (es. ) and conrm by pressing the
button;
At this point, the selection will be stored and relo-
aded each time in the future.
4. Follow signs, “ ”, “ ” followed by the
symbol of closed gate “- - - - ”.
Following ignitions
If you have already saved a conguration, pro-
ceed as follows:
Apply power, the display shows in sequence the
writing “
”, “ ”, “ ” followed by the
symbol of closed gate “- - - - ”.
Modify the existing conguration
If you have already saved a conguration and you
want to change it, proceed as follows:
1. Hold down the button and give power, the di-
splay shows in sequence the writing “
” and
“
” ashing;
2. Press the
button and hold for 5 seconds until
the display shows
(the value changes to
match the previous conguration used) on the
display;
3. Acting on the and , select the new desired
conguration depending on the type of installa-
tion (es. ) and conrm by pressing the
button;
Stop the reconguration procedure prior
to conrmation, involves loading the previous
conguration by the control panel without any
modication.
However, if the reconguration procedure is
brought to an end, the new conguration will
take the place of the previous one and will be
reloaded each time in the future.
4. Follow signs, “
”, “ ” followed by the
symbol of closed gate “- - - - ”.
Sliding gates
Swing gates
Overhead doors
Barriers
Sectional doors
