OPERATING PARAMETERS
TYPE 00 - 01 - 03 ONLY: Adjustment of the opening stroke margin: it adjusts the duration of the last part of
the stroke during which an obstacle is interpreted as a stroke, blocking the motor without performing the
inversion.
For motors with encoders, the set value indicates the number of revolutions of the rotor; while for motors
without encoder, the value is expressed in% of the maximum stroke.
Warning: for motors without encoder, if P035 (duration slow-down while opening) is >10%, it forces the
stroke detection margin so that it’s the same than the slow-down.
1..................255 (motors with encoder)
1%…............100% (motors without encoder)
TYPE 02 - 04 ONLY: Duration adjustment for the secondary force in closing: adjusts the duration of the last
part of the closing movement, in which the force is managed separately with P039. The value is expressed
in number of revolutions of the rotor.
0...................................255
TYPE 00 - 01 - 03 ONLY: Adjustment of the closing stroke margin: it adjusts the duration of the last part of
the stroke during which an obstacle is interpreted as a stroke, blocking the motor without performing the
inversion.
For motors with encoders, the set value indicates the number of revolutions of the rotor; while for motors
without encoder, the value is expressed in % of the maximum stroke.
Warning: for motors without encoder, if P036 (duration slow-down while closing) is >10%, it forces the stroke
detection margin so that it’s the same than the slow-down.
1..................255 (motors with encoder)
1%…............100% (motors without encoder)
TYPE 02 - 04 ONLY: Adjustment of the stop-margin in closing: adjusts the duration of the last part of the
closing movement, in which an obstacle is seen as a stop, causing the motor to stop without reversal on the
obstacle. The value is expressed in number of revolutions of the rotor.
1...................................255
TYPE 00 - 01 - 03 ONLY: Operators force adjustment at stroke arrival - If=0, setting off (the force value on
the stroke is calculated automatically) - If≠0 (operators with encoder) it indicates the force value (expressed
in% of the max value) set in the last length - If≠0 (operators without encoder), max speed is activated during
last length.
0%tot…...........................100%tot
TYPE 02 - 04 ONLY: Force adjustment in the stop margin in closing, its duration is set through P059.
0%tot…...........................100%tot
Unused parameter
Electric-lock output operating: If=0 “boost” output for electric-lock art.110 power supply, If=1 24V output
controlled by the ELOCK_IN input as pulsed mode,If=2 24V output controlled by the ELOCK_IN input as
step-by-step mode, If=3 electro-brake output for not self-locking operators, If=4 24V output for electric-lock
power supply via an external relay, If=5 24V output for electro-magnets power supply for barriers, If>5 24V
output controlled by the ELOCK_IN input as temporized mode (the set value indicates the switch-off delay in
seconds).
Warning: To adjust the activation/deactivation times in the 000 | 004 | 005 modes, use parameter P064.
• 000: “Boost” output for electric-lock art.110 power supply
• 001: “24V pulse output max 5W
• 002: “24V step-by-step output max 5W
• 003: “Electro-brake output for not self-locking operators
• 004: “Output for electric-lock power supply via an external
relay
• 005: “output for electro-magnets power supply for barriers
• >005: “24V temporized output max 5W
(6sec………………255sec)
Run direction inversion: If=1 automatically reverses the outputs open/close of the operators, avoiding having
to manual change the wiring when installing the operator in an inverted position.
Warning: Changing this parameter you need to change the parameters for the opening and closing limit
switches.
• 000: “Standard installation”
• 001: “Inverted installation”
Electric lock duration adjustment
If P062=000|004, adjust the activation time of the LOCK output;
If P062=005, adjust the deactivation time of the LOCK output;
Maintenance Operations-counter: if = 0 reset the counter and disables the intervention request , if>
0 indicates the number of operations (x 500) to be made before the control panel executes a 4 second
additional pre-ash to indicate the need of maintenance.
i.g.: If P065 = 050, operations number = 50x500 = 25000 operations
Warning: Before you set a new value of the counter-manoeuvres maintenance, the same must be reset by
setting P065= 0 and only later P065 = “new value”.
• 000: “Request Maintenance disabled
• >000: “Number of operations (x 500) for required
maintenance
(1...................................255)
Selection of operating ashing light output: If=0 intermittent ashing light output; If=1 Fixed ashing light
output (for ashing lights with intermittent interior circuits).
• 000: “intermittent ashing light output
• 001: “xed ashing light output
