9. Care, Cleaning, and Storage
• Avoid spilling food, beverages and other liquids on the radar
device.
• When you are not using or transporting the device, store it in its
original packaging.
• To clean the radar device, dust it with a soft clean cloth, which is
free of cleaning solutions.
10. Specications
10.1 Antenna Parameters
K-Band
IACP Type III
Nominal transmission frequency 24.150 GHz
Nominal horizontal beamwidth 12°
Polarization Linear
(Vertical)
Nominal microwave power output 7 mW
Maximum aperture power density <1 mW/cm2
10.2 Environment
Ambient operating temperatures -30ºC to +70ºC
Maximum humidity 90% relative humidity
(non-condensing) at 37°C
10.3 Speed Range Parameters
Speed Display Ranges Minimum Maximum
kph 20 337
10.4 Power Consumption Parameters
GHD
Supply voltage range 8.5VDC – 16.5VDC
Low voltage trip with antenna on 8.5VDC
SCOUT
Supply voltage range (with power cord) 8.5VDC - 16.5VDC
Low voltage trip with antenna on
(with power cord) 8.5VDC
Battery supply voltage 7.2VDC
Battery low voltage trip w/antenna on 6.3VDC
GHD AND SCOUT when using power cord
All currents measured at 13.8VDC with backlight on and speaker on
(volume = 4).
Standby (antenna o ) .105 amperes
Antenna ON (no targets displayed) .170 amperes
Antenna ON ( "55" target displayed) .172 amperes
Antenna OFF (segment check "888 888") .116 amperes
Antenna ON (segment check "888 888") .180 amperes
10.5 Accuracy
The speed calculations of any radar Decatur Electronics produces are
100% accurate. The display precision is as follows:
± 1 unit of measure in stationary mode of operation.
25/Aug/2010
31
