V. Specification
5.1 USB Connector
The USB connector type A is available to communicate with the computer tool or to
supply the programmer in Standalone mode. When in Standalone mode, the SF600Plus
has to be supplied through the USB connector or the 5V power jack. This could be
achieved by:
- Connecting the SF600Plus to a computer for the USB power
- Connecting the SF600Plus to a standard USB Hub (500mA min)
- Connecting the SF600Plus to the 5V/1A power adaptor through the power jack
USB Power supply specification:
- Vdd = 5V ± 5%
- Idd min = 500mA
5.2 DC and IO characteristics
5.2.1 Socket DC Characteristics
User can adjust the power supply of the target Serial Flash from the software interface.
The Vcc can be set from 1.8V to 3.8V.
The SPI signals levels are generated according to the Vcc selected.
5.2.2 ICP DC and AC characteristics
The ICP connector is a 10x2 pin header straight type with 2.54mm pitch. It is used to
control the application SPI Flash, and if necessary supply the SPI Flash, provide the high
voltage to the SPI Flash, or reset the application chipset, etc.
Table 6: SF600 and SF600Plus Pin Header description:
1
Vpp
CS2
2
3
CS1
Vcc
4
5
MISO/DQ1
Hold/DQ3
6
7
Wp/DQ2
CKL
8
9
GND
MOSI/DQ0
10
11
NC
Reset/IO3
12
13
NC
NC
14
15
NC
NC
16
17
NC
NC
18
19
GPIO1
GPIO2
20
