Definox DCX3 - Page 41

MAINTENANCE NOTICE
NM-230 index 18 Page 41/55 September 2020
9.3 DCX3 STANDARD REGULATING VALVE, ELASTOMER AND SECTION /2
A B C
STANDARD PLUG
STANDARD PLUG SECTION
/2
STD PLUG VERY SMALL
SECTION
D E
SEALING PLUG ELASTOMER
SEAL
SEALING PLUG ELASTOMER
SEAL SECTION /2
Seal kit family (Standard): B1, B2 or B3
Seal kit family (Elastomer): C1, C2 or C3
(According to material grade)
