Yacht Manual DEHLER 35
27 - 63
FIGURE 10: ENGINE INSTALLATION
Components
1 = Inboard diesel 2 = Saildrive 3 = Zinc ring
4 = Folding propeller 5 = Gasket 6 = Water collector
7 = Exhaust pipe 8 = Swan’s neck 9 = Outlet
IMPORTANT
Before you start the engine, take care,
that the cooling water valve is open.
Every time after starting the engine, you should check that cooling
water is being expelled with the exhaust fumes at the outlet!
4.1.2 Propeller
The yacht can be fitted with either a fixed screw or a folding screw.
IMPORTANT
In freshwater areas the zinc ring (3) must be replaced by
a magnesium ring.
