Dehler 35 - Arrangement of Main Fuses

Yacht Manual DEHLER 35
33 - 63
4.5.2 Arrangement of main fuses
The following main fuses are to be found under the saloon sofa port side behind the batteries
– depending on the equipment:
FIGURE 17: MAIN FUSES
1= Anchor winch 2= General consumption
3= steady plus
Further distribution to the “general consumption” is via the power circuit distributor,
(switch board) above the starboard chart table.
3
1
2
3
