Yacht Manual DEHLER 35
30 - 63
4.1 Fresh water, drinking water
The Dehler 35 has a polyurethane water tank, with a capacity of 130 l. It is installed under
sofa portside saloon. The filler cap is on the portside on the coaming. An electric pressure
water pump with a secondary surge tank supplies the sink and the washbasin in the toilet area.
A heat exchanger with a 22 l capacity is installed for the production of hot water. It is
situated in the starboard rear storage space
4.2.1 Cockpit shower
The fresh water tank also supplies
the cockpit shower. The unit is
installed on the cockpit starboard.
Components
1. Ventilation tank
2. Filler cap
3. Water tank
4. Pressure water pump
5. Hand washbasin outlet
6. cold water pipe
7. hot water supply
8. heat exchanger
FIGURE 13: DRINKING WATER
