4.5.4 Additional fuses
Apart from the fuses on the control panel and in the companion way, three more “in-line” fine wire
fuses have been installed, in each case a 2 A fine fuse in the control cables of the indicator for the
consumer batteries. An additional “delay action” 5 A fine wire fuse protects the cable for the engine
compartment ventilation.
4.5.5 Control panel data
Manufactured by Philippi
Circuits with thermal protected switches
Ammeter
Switch
Combined indicator voltmeter
for water/diesel + holding tank (optional) indicators
12 V socket
Direct current consumers
The main circuits are the following:
Navigation lights Refrigeration unit for cool-box
Water pumps Engine instruments/Tank indicator
VHF Radio/ radio Electronic navigation instruments
Auxiliary consumption Bilge pumps, Shower/Bilge
Anchor winch Self steering gear
4.5.6 Battery Charging
The yacht is equipped with a 12 V 75 Ah starter battery, placed under the berths of the stern
cabin port side. Depending on the equipment, the installed consumer batteries are 1 x 95 Ah
AGM or optionally 2 x 95 Ah AGM, installed under the port side salon berths. Both batteries
are maintenance-free and protected against leakage.
The batteries are charged via the engine alternator. As soon as the shore connection is
switched on, the battery charger starts charging all batteries.
Alternating current consumers
The fixed 230 V connections are for the battery charger and hot water provision. The 230 V
sockets in the panel of the land line unit are intended for carrying out small repairs with
electrical machines being on a sailing trip or for connecting other comfort consumers.
REMEMBER
The power of shore connections is usually limited. Max. 600 – 800
Watt.
