Deif GPC-3 Quick Start Guide

VT and CT settings
No. Setting Min.
Max.
Factory
setting
Notes Ref. Description
6040 G transformer
6041 G transform-
er
U primary 100 V
25000 V
400 V Designer's
Reference
Handbook
If no voltage transformer
is present, the primary
and secondary side val-
ues are set to generator
nominal value.
6042 G transform-
er
U secon-
dary
100 V
690 V
400 V
6043 G transform-
er
I primary 5 A
9000 A
1000 A
6044 G transform-
er
I secondary 1 A
5 A
5 A
6050 Busbar settings
6051 BB settings U primary 100 V
25000 V
400 V Designer's
Reference
Handbook
If no voltage transformer
is present, the primary
and secondary side val-
ues are set to generator
nominal value
6052 BB settings U secon-
dary
100 V
690 V
400 V
6053 BB settings U BB nom. 100 V
25000 V
400 V
4.2 Getting started with the DEIF utility software (USW)
4.2.1 Downloading the software
1. Go to www.deif.com
2. Select Documentation & Software
3. Select Software download
4. In the dropdown menu, select Multi-line 2 utility software v.3.x
5. Fill in your e-mail address and click “Submit”
You will now receive an e-mail containing a link. Click the link and follow the instructions.
The USW is now installed on your computer.
4.2.2 Installation of USB drivers
On Windows Vista machines, the USB drivers are installed automatically.
This is the procedure on Windows XP machines:
When you connect the DEIF product, Windows XP will launch two "Hardware Wizards". Two drivers are in-
stalled, so please let Windows execute both "Found new Hardware Wizard"s.
We recommend letting the Hardware Wizard install the software automatically by choosing the "Recommen-
ded" option. If the "Advanced" option is chosen, the needed files are available from the USW3 installation
folder (default: C:\Program Files\DEIF\USW3\) in the "USB driver files/source PreInstaller" folder.
Please select "Continue Anyway" if a "Hardware Installation" warning (see screenshot below) appears during
the installation.
ML-2 quick start guide 4189340603 UK
The first steps
DEIF A/S Page 17 of 23
