PPM Installation Instructions
DEIF A/S Page 17 of 69
106 Configurable. User-programmable This input is programmable from the PC utility software.
This input has wire break supervision and therefore
needs a potentially free contact. The wire break
resistor is 100 .
110 Configurable/Semi-auto mode This input is programmable from the PC utility
software/Input for activating the semi-auto mode (pulse
signal).
111 Configurable/Auto mode This input is programmable from the PC utility
software/Input for activating the auto mode (pulse
signal).
112 Configurable/Split mode This input is programmable from the PC utility
software/Input for activating the split mode (pulse
signal).
113 Configurable/Shaft (or shore) mode This input is programmable from the PC utility
software/Input for activating the shaft (or shore) mode
(pulse signal).
114 Emergency stop The emergency stop input has been activated.
The engine is shutting down.
115 Ready for operation The diesel engine is ready for operation. When this
input is OFF, the diesel engine is blocked for start/CB
ON.
116 Running feedback The diesel engine has achieved the running status =
ON.
117 Remote start Remote input for start + CB ON. (Only available in
SEMI-AUTO mode).
118 Remote stop Remote input for CB OFF + stop. (Only available in
SEMI-AUTO mode).
Analogue transducer inputs
Term. Name Function
98 HC 1 power feedback/configurable Analogue power feedback for heavy consumer no. 1
regarding the adjustable setpoint. 4..20 mA (0 kW…HC
1 max. kW)/Configurable. User-programmable.
100 HC 2 power feedback/configurable Analogue power feedback for heavy consumer no. 2
regarding to the adjustable setpoint. 4..20 mA (0
kW…HC 2 max. kW)/Configurable. User-programmable.
102 Configurable. User programmable Configurable analogue alarm input.
Adjustable setpoint (4..20 mA).
