PPM Installation Instructions
DEIF A/S Page 62 of 69
Electronic speed governor
If necessary, the current outputs can be converted to voltage using a resistor across the
terminals (250 will convert the +/-20 mA into +/-5V DC).
AVR with analogue outputs (requires option D)
If necessary, the current outputs can be converted to voltage using a resistor across the
terminals (250 will convert the +/-20 mA into +/-5V DC).
For further information on how to connect the analogue output to the most
common speed governors please refer to:
Application Notes, Interfacing DEIF equipment to governors and AVRs,
document number 4189340149
at www.deif.com.
For further information on how to connect the analogue output to the most
common AVRs please refer to:
Application Notes, Interfacing DEIF equipment to governors and AVRs,
document number 4189340149
at www.deif.com.
