Deif PPU - Wirings; AC Connections (3-phase)

PPM Installation Instructions
DEIF A/S Page 57 of 69
8. Wirings
AC connections (3-phase)
The neutral line (N) connection is not necessary for correct measurement. 3-
phase without neutral is also possible. The current transformer ground
connection can be on s1 or s2 connection, whichever is preferred. Fuses: 2A
slow-blow.
