PPM Installation Instructions
DEIF A/S Page 31 of 69
114 Emergency stop The emergency stop input has been activated.
The engine is shutting down.
115 Ready for operation The diesel engine is ready for operation. When this
input is OFF, the diesel engine is blocked for start/CB
ON.
116 Running feedback The diesel engine has achieved the running status =
ON.
117 Remote start Remote input for start + CB ON. (Only available in
SEMI-AUTO mode).
118 Remote stop Remote input for CB OFF + stop. (Only available in
SEMI-AUTO mode).
Analogue transducer inputs
Term. Name Function
98 HC 1 power feedback/configurable Analogue power feedback for heavy consumer no. 1
regarding the adjustable setpoint. 4..20 mA (0 kW…HC
1 max. kW/Configurable. User-programmable.
100 HC 2 power feedback/configurable Analogue power feedback for heavy consumer no. 2
regarding the adjustable setpoint. 4..20 mA (0 kW…HC
2 max. kW)/Configurable. User-programmable.
102 Configurable. User-programmable Configurable analogue alarm input.
Adjustable setpoint (4..20 mA).
