PPM Installation Instructions
DEIF A/S Page 43 of 69
software.
113 Configurable. User-programmable This input is programmable from the PC utility
software.
114 Emergency stop The emergency stop input has been activated. If
running on the SG, the CB for the SG will be tripped. If
the TB is opened due to a blackout, then the mode will
change to AUTO, and the generators will perform a
blackout start.
115 Ready for operation The SG is ready for operation. When this input is
OFF, the SG is blocked for start/CB ON.
116 Running feedback The SG has achieved the running status = ON.
117 Configurable. User-programmable This input is programmable from the PC utility
software
118 Configurable. User-programmable This input is programmable from the PC utility
software
Analogue transducer inputs
Term. Name Function
98 HC 1 power feedback/configurable Analogue power feedback for heavy consumer no. 1
regarding the adjustable setpoint. 4..20 mA (0 kW…HC 1
max. kW)/Configurable. User-programmable.
100 HC 2 power feedback/configurable Analogue power feedback for heavy consumer no. 2
regarding the adjustable setpoint. 4..20 mA (0 kW…HC 2
max. kW)/Configurable. User-programmable.
102 Configurable Configurable analogue alarm input.
Adjustable setpoint. 4..20 mA.
