Delem DA-52s User Manual

No unauthorized copying allowed
Format Number Issue
Note Redrawn
Redrawn
Date Date
Date
Description Description Note
DrawnMeasures in mm,unless
otherwise specified
Scale
Luchthavenweg 42, 5657 EB Eindhoven, the NETHERLANDS
A3
HNF
20-06-2012
DA-52s cables & connectors
8079-902 A
ANALOG B
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
ANALOG A
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
1 2 3 4 5
6 7 8 9
COM
1 2 3 4 5
6 7 8 9
ENCODER Y2
VALV E
1 2 3 4 5 6 7 8
POWER
1
2
3
4
5
6
7
1 2 3 4 5
6 7 8 9
ENCODER AUX. 1
1 2 3 4 5
6 7 8 9
ENCODER AUX. 2
1 2 3 4 5
6 7 8 9
ENCODER Y1
I/O
T
USB
9 10 11 12 13 14 15 16
I/O1 I/O2 I/O3 I/O4 I/O5 I/O6 I/O7 I/O8 +24V 0V
+24V +24V 0V
+24V
0V 0V
OUT9 OUT10 OUT11 OUT12 IN13 IN14 IN15 IN16
OUT17 OUT18 OUT19 OUT20 IN21 IN22 IN23 IN24
OUT25 OUT26 OUT27 OUT28 IN29 IN30 IN31 IN32
INPUTS / OUTPUTS
CN3 CN4 CN5 CN6
CN1
CN2
CN7
CN8
CN9
CN10
CN12
CN14 CN16 CN20
5885-011/-
Eindhoven
POWER 24V DC
Type: DA-52s
Serial number:
Made in the Netherlands8079-00N
NNNNN
ANALOG B
ENCODER Y1
ENCODER Y2
ANALOG A
5060-005
15p.SubD Female
DC-SUBD-15-F-CP
5060-004
15p.SubD Male
DC-SUBD-15-M-CP
DC-161586 DC-177988 DC-178909
Clamping-yoke
connection
(screw)
Spring connection Spring connection
+ Led indication
1 x Power LED
8 x I/O LED
DC-SUBD-9-M-CP
5060-001
9p.SubD Male
DC-SUBD-9-M-CP
5060-001
9p.SubD Male
DC-SUBD-9-M-CP
5060-001
9p.SubD Male
DC-SUBD-9-M-CP
5060-001
9p.SubD Male
ENCODER AUX 1
ENCODER AUX 2
I/O, INPUTS & OUTPUTS
DK-1079-003 4.0 m
Full version:
or
Pressure control version only:
DK-1079-007
1079-003/-
4.0 m
DK-1079-004 6.0 m DK-1079-005 9.0 m
DK24-N40 4.0 m DK24-N50 5.0 m DK24-N100 10.0 m
1128-00N/n
POWER 24VDC
Clamping-yoke
connection
(screw)
Spring
connection
DK-1079-008 6.0 m DK-1079-009 9.0 m
EXTERNAL USB
DC-USB
5181-001
USB-A/B-cable 0.65 M
