Delem
V1204, 2.4
MR Machine Ready Signal that indicates the machine is ready. When it is
low, the control cannot be started. When it is high, the
control can be started and the Hours counter (parameter
91) keeps track of the time.
Digital output signals
Code Name Description
RDY Ready Ready signal, to indicate that control has finished
positioning. In case of a shear system, this signal
becomes high when the axis is in position and the Gap
is set correctly.
EOC End Of Cycle Program or step is finished
EOS End Of Stroke Stroke is finished, either position is reached or stroke
time has elapsed
F1 Function output 1 General purpose programmable output
F2 Function output 2 General purpose programmable output
G+ Gap open Increase gap opening
G- Gap close Reduce gap opening
A+ Angle increase Increase angle between table and shear
A- Angle decrease Reduce angle between table and shear
+ Opening Opening command for AC motor
- Closing Closing command for AC motor
++ Fast opening Fast opening command for AC motor
-- Fast closing Fast closing command for AC motor
BRK Brake (AC) Brake signal for AC motor, equipped with brake
system. This signal is ‘low-active’: during positioning
the signal is high, it will become low when the brake
must be applied.
Analogue input signals
Code Name Description
SFB Stroke Feedback Position feedback of the shear, in case Stroke feedback
is enabled.
GFB Gap feedback Position feedback of the Gap opening, in case Gap
system with position feedback is enabled.
PFB Position feedback Position feedback of axis position.
AFB Angle feedback Feedback of angle value, in case angle control is
installed.
Note:
The encoder input is also regarded as an analogue input.
