Delem
V0804, 3.4
2.2. Test functions
In 1 - 4
These digits refer to the digital inputs of the control. To test the digital inputs, apply 24V to
the inputs and check if they change to ‘1’.
Out 1-8
These digits refer to the digital outputs of the control. To change an output, move the cursor to
the required output number and press ENTER.
Ana/Enc
Column with several analog I/O and encoder signals.
In
Digital input voltage, displayed as 8-bit AD-value, 0 - 255
Out
Digital output voltage, 12-bit DA-value, -2047 - 2047.
Off
Offset voltage for digital output, 12-bit DA-value.
Enc
Encoder counting.
Ref
Test the encoder reference input on/off.
When switched ON, the Enc-value is reset to zero when a reference pulse
is read from the encoder.
When switched OFF, the ref. pulse is ignored. The Enc-value is
incremented or decremented depending on the rotation.
To Next Page
