Delem
V1204, 2.12
Bipolair: Unipolair:
DAC-310
M
0 +/- 10V
DAC-310
M
0 - 10V + -
+ -
In case of a 2-speed unipolar system, you should consider your I/O configuration with care.
The illustration above is an example of a 2-speed unipolar implementation. The outputs 1 and
2 of the DAC are used for indication of positive and negative movement. Since the speed
values can be distinguished from the analog output, both signals for positive movement can be
put on the same output. The same is valid for the two signals for negative movement.
