Dell EMC Data Domain FS15 SSD Shelf User Manual

ES30 and FS15 hardware specifications
Note
All ratings assume a fully configured ES30 or FS15.
Table 28 ES30 and FS15 hardware specifications
Specification Description
AC line voltage 100 to 240 Vac ± 10%, single-phase, 47 to 63
Hz
AC line current (operating maximum) 2.8 A max at 100 Vac, 1.4 A max at 200 Vac
Power consumption (operating maximum) 280 VA (235 W) max
Power factor 0.98 min at full load, low voltage
Heat dissipation (operating maximum) 8.46 x 10
5
J/hr, (800 Btu/hr) max
Dimensions (rack mounted, with bezel)
l
Width: 17.62" (45 cm) Depth: 14”
(35.56cm)
l
Height: 5.25” (13.34cm) 3 RU
Maximum Weight 68 lbs (30.8 kg)
Operating Temperature
l
Ambient temperature: 10
o
C to 35
o
C (50
o
F to 95
o
F)
l
Temperature gradient: 10
o
C/hr (180
o
F/hr)
l
Relative humidity extremes: 20% to 80%
noncondensing
Recommended Operating Relative Humidity 40% to 55% noncondensing
Non-Operating Temperature
l
Ambient temperature: -40
o
C to 65
o
C
(-40
o
F to 149
o
F)
l
Temperature gradient: 25
o
C/hr
(45
o
F/hr)
l
Relative humidity: 10% to 90%
noncondensing
Hardware Specifications
130 Data Domain ES30 Expansion Shelf and FS15 SSD Shelf Hardware Guide
